ICT COMM SERIES ICT12-12 Desktop 12V DC 12A Power Supply

The next generation ICT Comm Series desktop power supplies are designed and manufactured in North America for high quality, reliability, and assured delivery. The new models are available with 12 volt DC output, and incorporate a common sized chassis and simplified model numbers for easy ordering and deployment. 10A of power to easily convert a mobile radio into a base station, with 12A burst when more power is needed for a short duration. A new line of Radio Covers is available for LMR base station applications. ICT also offers 220 volts AC input models and a 48 volt DC output model for wireless broadband applications, available by special order.

• 12 Amp models with 12 volt DC output (10A Continuous output)
• Designed and built in North America for highest reliability

• Common sized chassis for all models
• CSA, FCC Class B, ROHS approved
• Broad range of new land mobile radio covers
• Heavy duty terminal block output connectors
• Built in protection features
• Rack mounting option available
• 2 year warranty



Dimensions (inches) L x W x H	8.0 x 7.1 x 2.2
Dimensions (mm) L x W x H	203 x 180 x 56
Weight (lbs)	2.7 lbs
Weight (kg)	1.23 kg
AC Input Connector	IEC 60320 with NEMA5-15P to C13 (detachable 6 ft. / 1.8 m cord included)
DC Output Connector	Terminal Block, M4.0

Over Current	+5% of rated current
Over Voltage	+5% of rated voltage
Short Circuit, Overload	Constant current limit with current foldback, recovers when short / overload condition is removed

Safety	CSA/UL 60950
EMI	FCC Part 15, Class B
Other	ROHS

ICT-RM2U	19 inch, 2RU rack mount shelf
Land Mobile Radio Covers	The new Comm Series family uses new radio covers from the previous generation. Refer to the Jan. 20, 2020 ICT Radio Cover Guide at www.ict-power.com for full selection
