VHF Fixed Marine Radio RS-507M - Class D

VHF Fixed Marine Radio RS-507M - Class D

Enjoy prompt shipping from the Toronto warehouse.
Regular price $105.79 CAD
Regular price Sale price $105.79 CAD
Sale Sold out
Shipping calculated at checkout.

Promotions

Login to your account or create one, to see what QSO Rewards are waiting for you!

Shopify secure badge

Quick Specs

Scoll down for more information about this item.

VHF Fixed Marine Radio RS-507M - Class D



The Recent RS-507M is a high-performance Class D Fixed Mount VHF Marine Radio designed to meet the demanding communication needs of marine enthusiasts and professionals. This radio is packed with a range of advanced features and functions that ensure reliable communication and safety at sea.

One of the key features of the RS-507M is its rugged and durable construction. It is built to withstand the harsh marine environment and is waterproof and dustproof, with an IP67 rating. This means that it can be submerged in up to 1 meter of water for 30 minutes without any damage. The radio is also designed to resist corrosion, making it ideal for use in saltwater environments.

The RS-507M is equipped with a large, easy-to-read LCD display that provides clear and detailed information about the radio's functions and status. The display also features adjustable brightness, making it easy to read in any lighting condition.

The radio offers a powerful transmission output of 25 watts, ensuring clear and reliable communication over long distances. It also features a built-in noise-cancelling microphone that helps to reduce background noise and improve the clarity of your voice transmissions.

Another notable feature of the RS-507M is its advanced digital selective calling (DSC) functionality. This feature allows you to send and receive distress signals and other important information with the touch of a button. The radio also supports position tracking and group calling, making it easy to communicate with other vessels and coast guard stations when connected to an external GPS receiver.

The RS-507M also includes a range of other useful features, such as a built-in FM radio receiver, weather alerts, and a dual-watch function that allows you to monitor two channels at once.

In terms of installation, the RS-507M is designed to be easy to mount and install. It comes with a flush-mount kit and a quick-release bracket, making it simple to remove and replace the radio if needed.

Overall, the Recent RS-507M is a versatile and reliable Class D Fixed Mount VHF Marine Radio that is packed with advanced features and functions. Its rugged construction, powerful transmission output, and advanced DSC functionality make it an excellent choice for marine enthusiasts and professionals alike.



General
Frequency Range (Marine Band) TX:156.025-157.425MHz
RX:156.050-163.275MHz
Channel No. 88 channels
Modulation mode FM(16K0G3E) / DSC(16K0G2B)
Frequency Stability ±10ppm
Work Voltage DC13.8V (±15%)
Operating Temperature -20°C~+60°C
Antenna Impedance 50ohm
Dimensions 153x67x152mm
Weight 742g
Transmitter
RF Power Output 25W/1W
Maximum Frequency Deviation ±5KHz
Spurious and Harmonic <= -70dB(H)
<= -56dB(L)
Adjacent Channel Selectivity >=70dB
TX Audio Distortion >=10%
Current Consumption <= 5.5A (High power)
<= 1.5A (Low power)
Microphone Impedance 2K ohm
Receiver
RX Sensitivity <= 0.2µV
Squelch Sensitivity ±5KHz
Adjacent Channel Selectivity >=70dB
Intermodulation Anti-interference >=70dB
Spurious Response Rejection >=70dB
View full details

Description

VHF Fixed Marine Radio RS-507M - Class D



The Recent RS-507M is a high-performance Class D Fixed Mount VHF Marine Radio designed to meet the demanding communication needs of marine enthusiasts and professionals. This radio is packed with a range of advanced features and functions that ensure reliable communication and safety at sea.

One of the key features of the RS-507M is its rugged and durable construction. It is built to withstand the harsh marine environment and is waterproof and dustproof, with an IP67 rating. This means that it can be submerged in up to 1 meter of water for 30 minutes without any damage. The radio is also designed to resist corrosion, making it ideal for use in saltwater environments.

The RS-507M is equipped with a large, easy-to-read LCD display that provides clear and detailed information about the radio's functions and status. The display also features adjustable brightness, making it easy to read in any lighting condition.

The radio offers a powerful transmission output of 25 watts, ensuring clear and reliable communication over long distances. It also features a built-in noise-cancelling microphone that helps to reduce background noise and improve the clarity of your voice transmissions.

Another notable feature of the RS-507M is its advanced digital selective calling (DSC) functionality. This feature allows you to send and receive distress signals and other important information with the touch of a button. The radio also supports position tracking and group calling, making it easy to communicate with other vessels and coast guard stations when connected to an external GPS receiver.

The RS-507M also includes a range of other useful features, such as a built-in FM radio receiver, weather alerts, and a dual-watch function that allows you to monitor two channels at once.

In terms of installation, the RS-507M is designed to be easy to mount and install. It comes with a flush-mount kit and a quick-release bracket, making it simple to remove and replace the radio if needed.

Overall, the Recent RS-507M is a versatile and reliable Class D Fixed Mount VHF Marine Radio that is packed with advanced features and functions. Its rugged construction, powerful transmission output, and advanced DSC functionality make it an excellent choice for marine enthusiasts and professionals alike.



General
Frequency Range (Marine Band) TX:156.025-157.425MHz
RX:156.050-163.275MHz
Channel No. 88 channels
Modulation mode FM(16K0G3E) / DSC(16K0G2B)
Frequency Stability ±10ppm
Work Voltage DC13.8V (±15%)
Operating Temperature -20°C~+60°C
Antenna Impedance 50ohm
Dimensions 153x67x152mm
Weight 742g
Transmitter
RF Power Output 25W/1W
Maximum Frequency Deviation ±5KHz
Spurious and Harmonic <= -70dB(H)
<= -56dB(L)
Adjacent Channel Selectivity >=70dB
TX Audio Distortion >=10%
Current Consumption <= 5.5A (High power)
<= 1.5A (Low power)
Microphone Impedance 2K ohm
Receiver
RX Sensitivity <= 0.2µV
Squelch Sensitivity ±5KHz
Adjacent Channel Selectivity >=70dB
Intermodulation Anti-interference >=70dB
Spurious Response Rejection >=70dB
