Quansheng UV-K5(8) Amateur Ham Radio

Quansheng UV-K5(8) Amateur Ham Radio

Enjoy prompt shipping from the Toronto warehouse.
Prix habituel $69.99 CAD
Prix habituel Prix soldé $69.99 CAD
Vente Épuisé
Frais d'expédition calculés à l'étape de paiement.

Promotions

Login to your account or create one, to see what QSO Rewards are waiting for you!

Shopify secure badge

Quick Specs

  • 144-148
  • 430-450
  • SMA Female (Chinese Style)

K Plug

5W

  • FM

Scoll down for more information about this item.

- Frequency Range:

  • 144-148 / 430-450 MHz

Quansheng UV-K5(8) Amateur Radio

Make waves with the Quansheng UV-K5(8) Amateur Ham Radio. This dual band radio packs a punch with 5W RF power and an upgraded speaker for crystal clear communication. Stay prepared with its NOAA weather receiver for real-time weather updates. Time to ham it up!

Quansheng UV - K5(8) Amateur Radio NOAA Emergency Weather

Experience the ultimate in amateur ham radio with the Quansheng UV-K5(8). Stay connected with DTMF tones and FM radio, while charging with USB TYPE-C or base charger. Never miss a beat with frequency scanning and a convenient flash light. Stored with 200 channels and a wide/narrow band option. Choose your power setting, Hi/Mid/Low, for optimal performance. Stay connected, stay prepared!

Quansheng UV - K5(8) Amateur Radio NOAA Emergency Weather

Become an amateur ham operator with ease with the Quansheng UV-K5(8) radio! Effortlessly tune in to your desired frequency with the built-in frequency counter. Say goodbye to fumbling with knobs and dials, and hello to a smoother communication experience. (Bonus: impress your friends with your newfound radio expertise!)

IC ID: 30518-UVK5

Quansheng UV - K5(8) Amateur Radio NOAA Emergency Weather

GENERAL SPECIFICATIONS
Number of channels

200

Number of FM radios

16

Frequency stability

±1ppm

Size

115mmX60mmX37.5mm

Weight

234g

Working temperature

-20℃+60℃

Antenna impedance

50Ω

Modulation mode

FM:11KOF3E(12.5KHz),16K0F3E(25KHz)

Number of NOAA channels

10

Battery capacity

1600mAh

RECEIVE
Reference Sensitivity

FM(12dB SINAD)

  • F1(50∽76) -121dBm
  • F2(108∽135.9975) -121dBm
  • F3(136∽173.9975) -123dBm
  • F4(174∽349.9975) -123dBm
  • F5(350∽399.9975) -123dBm
  • F6(400∽469.9975) -123dBm
  • F7(470∽599.9975) -121dBm

WFM(20dB SINAD)

  • WFM(76∽108) -110dBm

AM(10dB S/N)

  • F2(108∽135.9975) -113dBm
Audio Power

≥0.5W

Audio Distortion

≤10%

Transmit
Frequency

VHF: 144∽148MHz UHF: 430∽440MHz

Transmitting Power

≤5W

Emission Current

≤1.5A

Maximum Frequency Deviation

≤5KHz(25KHz),≤2.5KHz(12.5KHz)

Modulation Distortion

≤5%

Stray Power

≤7.5uW

Adjacent Channel Power

70dB(25KHz),60dB(12.5KHz)

Residual Modulation

40dB



Afficher tous les détails

Description

- Frequency Range:

  • 144-148 / 430-450 MHz

Quansheng UV-K5(8) Amateur Radio

Make waves with the Quansheng UV-K5(8) Amateur Ham Radio. This dual band radio packs a punch with 5W RF power and an upgraded speaker for crystal clear communication. Stay prepared with its NOAA weather receiver for real-time weather updates. Time to ham it up!

Quansheng UV - K5(8) Amateur Radio NOAA Emergency Weather

Experience the ultimate in amateur ham radio with the Quansheng UV-K5(8). Stay connected with DTMF tones and FM radio, while charging with USB TYPE-C or base charger. Never miss a beat with frequency scanning and a convenient flash light. Stored with 200 channels and a wide/narrow band option. Choose your power setting, Hi/Mid/Low, for optimal performance. Stay connected, stay prepared!

Quansheng UV - K5(8) Amateur Radio NOAA Emergency Weather

Become an amateur ham operator with ease with the Quansheng UV-K5(8) radio! Effortlessly tune in to your desired frequency with the built-in frequency counter. Say goodbye to fumbling with knobs and dials, and hello to a smoother communication experience. (Bonus: impress your friends with your newfound radio expertise!)

IC ID: 30518-UVK5

Quansheng UV - K5(8) Amateur Radio NOAA Emergency Weather

GENERAL SPECIFICATIONS
Number of channels

200

Number of FM radios

16

Frequency stability

±1ppm

Size

115mmX60mmX37.5mm

Weight

234g

Working temperature

-20℃+60℃

Antenna impedance

50Ω

Modulation mode

FM:11KOF3E(12.5KHz),16K0F3E(25KHz)

Number of NOAA channels

10

Battery capacity

1600mAh

RECEIVE
Reference Sensitivity

FM(12dB SINAD)

  • F1(50∽76) -121dBm
  • F2(108∽135.9975) -121dBm
  • F3(136∽173.9975) -123dBm
  • F4(174∽349.9975) -123dBm
  • F5(350∽399.9975) -123dBm
  • F6(400∽469.9975) -123dBm
  • F7(470∽599.9975) -121dBm

WFM(20dB SINAD)

  • WFM(76∽108) -110dBm

AM(10dB S/N)

  • F2(108∽135.9975) -113dBm
Audio Power

≥0.5W

Audio Distortion

≤10%

Transmit
Frequency

VHF: 144∽148MHz UHF: 430∽440MHz

Transmitting Power

≤5W

Emission Current

≤1.5A

Maximum Frequency Deviation

≤5KHz(25KHz),≤2.5KHz(12.5KHz)

Modulation Distortion

≤5%

Stray Power

≤7.5uW

Adjacent Channel Power

70dB(25KHz),60dB(12.5KHz)

Residual Modulation

40dB
