N9 Northern Ontario FSR Edition Logging Road Back Country Walkie Talkie Two Way Radio

UV11(N9)

Baofeng

  • $99.99 CAD
Shipping calculated at checkout.


The N9 Northern Ontario FSR Edition Logging Road Back Country Walkie Talkie Two Way Radio is the product you didn't think you need, but once you have it, you will want another.

IC# 25962-P11UV

Stay safe on Northern Ontario logging roads and keep in touch with the Pofung P11UV Forest Service Road land mobile radio.

Simple user interface make this an ideal choice for recreational drivers who explore, and appreciate the safety and value of having a two way radio to keep in touch. With 4W of output power and a 1500MAh lithium ion battery your radio will run a full 8 hours before needing a charge. The 1W of audio output power will ensure loud and clear copies of incoming transmissions. If thats not enough features there are also the 11 NOAA weather channels programmed in for when mother nature decides to cast some grey overhead. Never be without the important information you need whether its coming from up ahead, or "weather" its coming from up above!

With the convenient USB charging interface you will never be far from a charging source to keep you safe and secure. Also included is a wrist strap and belt clip for easy on the go carrying, and of course the battery, desktop charger, and antenna.



A valid ISED Land Mobile License for Appendix N9 is required prior to deployment. If you need help please contact us for assistance!

 Please download the application from here. or visit the Spectrum Management System website here to apply online.

https://sms-sgs.ic.gc.ca/eic/site/sms-sgs-prod.nsf/eng/home



Commercial Frequency:

  • VHF: 138.025 - 173.975 (REQUIRES DEALER PROGRAMMING)
  • UHF: 406.125 - 429.975 (REQUIRES DEALER PROGRAMMING)
  • UHF: 450.025 - 469.975 (REQUIRES DEALER PROGRAMMING)



This radio is capable of the following frequencies, making it a good choice for logging roads and back country:

The common logging radio frequencies listed in the table below may be used in the authorized areas and in areas north of 51 degrees latitude in Ontario.

Recreational drivers on the logging roads require reliable vehicle to vehicle communications while on the roadways. For this reason, eight common logging channels (radio frequencies) have been made available for two-way, truck-to-truck radio communications while on certain designated roadways in Northern Ontario. The intent of these channels is to coordinate the safe movement of vehicles on logging roads rather than provide “chat lines” for truck operators. In order to minimize potential radio interference to other radio users, especially essential safety services, use of these channels is restricted to specific geographical areas.

It is very important to understand that use of any channel or frequency outside its authorized area could result in interference to other radio users. Such interference could create dangerous situations and jeopardize lives – including yours. The other radio user, for example, could be an ambulance system dispatching a first response team, or a municipal fire department dispatching a fire truck in a community. Misuse of a radio channel could also cause interference to a heart monitor at a local hospital, or a paging service trying to contact a doctor in order to respond to a sick child.

A valid ISED Land Mobile License for Appendix N9 is required prior to deployment. If you need help please contact us for assistance!

Frequencies and Conditions
Channel Frequency (MHz) Authorized area of operation
1 150.290 The districts of Thunder Bay and Sudbury; part of the District of Algoma, south of the CN Rail line.
2 159.270 East of Nipigon, north of Wawa, Chapleau, Watershed and west of Matheson and Elk Lake.
3 163.980 The districts of Cochrane, Algoma, Sudbury, Timiskaming, Nipissing, Manitoulin and Parry Sound; part of the District of Kenora, north of Red Lake; Highway 17 extending east to Pembroke, north of Highway 60 and all of Algonquin Park.
4 165.180 The districts of Kenora, Thunder Bay and west of Wawa and Hearst, except 50 km radius of Red Lake.
5 170.250 Sudbury, South on Highway 69 to Parry Sound; Sudbury, east on Highway 17 to Pembroke; north of Highway 60, all of Algonquin Park and north of Highway 141.
6 170.310 The districts of Kenora, Rainy River and Thunder Bay.
7 171.000 The districts of Kenora, Rainy River, Thunder Bay and west of Highway 129, Chapleau and Hearst.
8 172.065 The districts of Kenora, Rainy River, Thunder Bay, Algoma and Cochrane; part of the District of Sudbury, north of Cartier and Capreol, except the 50 km radius of Red Lake.



 Specifications:

  • Frequency Range:
    • 138.025 - 173.975 VHF
    • 406.125 - 469.975 UHF
  • Output power: 5 Watt
  • IC# 25962-P11UV
  • Battery Capacity: 1500mAH (Li-lon)
  • Operation Voltage: DC 7.4 V ± 10%
  • Frequency Stability: ± 2.5ppm
  • Operating Temperature: -20℃ to +60℃
  • Mode of Operation: Duplex (Repeaters) or Simplex (Direct Radio to Radio)
  • Antenna Impedance: 50ohm



Transmitter:

  • FM Modulation: 11K0F3E @ 12.5KHz
  • Adjacent Channel Power: 60dB @ 12.5KHz
  • Transmission current: ≤1600mA



Receiver Part:

  • Receive Sensitivity: 0.25μV(12dB SINAD)
  • Adjacent Channel Selectivity: ≥55dB @ 12.5KHz
  • Inter Modulation and Rejection: ≥55dB @ 12.5KHz
  • Conducted Spurious Emission: ≤-57dB @ 12.5KHz
  • Rated Audio Power Output: 1W @ 16 ohms
  • Receive current: ≤380mA
  • Rated Audio Distortion :≤5%

Box Contents:

  • P11UV FM Transceiver
  • 1500 Lithium Ion Battery
  • Battery Charger
  • Power Adapter
  • Belt Clip
  • Antenna
  • Wrist Strap
